内容 Parameter

数据 data

备注 Remarks

修磨刀具直径Grinding tool diameter

3-20mm

可根据刀具直径定制

Can also be customized according to tool diameter

磨削长度Grinding length

130mm

最大回转直径Maximum turning diameter

150mm

X轴行程Travel X-axis

300mm

Y轴行程Travel Y-axis

150mm

Z轴行程Travel Z-axis

150mm

X/Y/Z轴定位精度X/Y/Z axis positioning accuracy

≤0.006mm

X/Y/Z轴

≤0.004mm

X/Y/Z轴快速移位速度X/Y/Z axis rapid traverse speed

10m/min

A轴旋转角度A axis rotation angle

360°

C轴旋转角度C axis rotation angle

210°

主轴最高转速Spindle highest speed

6000rpm

砂轮杆连接Grinding wheel rod connection

BT30

可装砂轮内径The inner diameter of the wheel that can be installed

31.75mm

可装砂轮外径The outter diameter of the wheel that

125mm

可装砂轮片数The number of grinding wheels that can be mounted

3片

工件装夹方式Workpiece clamping method

W25气动装夹 W25 pneumatic clamp

可改液压装夹Hydraulic clamp

电主轴峰值功率Electric spindle power rating

3.5KW

X轴伺服马达功率The X axis servo motor power

0.4KW

Y轴伺服马达功率The Y axis servo motor power

0.4KW

Z轴伺服马达功率The Z axis servo motor power

0.6KW

A轴伺服马达功率The A axis servo motor power

0.1KW

C轴伺服马达功率The C axis servo motor power

0.1KW

直线导轨精密级Linear guide precision level

P级 P class

滚珠丝杆精密级Ball screw precision level

C3

3D探针3D probe

1个

数控系统CNC system

新代 New generation

台湾Taiwan

机床总功率约Total power of machine tool

5.5KW

机床重量约Machine weight

1000KG

机床尺寸约Machine size

宽1150×深2215×高1770(mm)
